| Business Type | Retailer, Distributor |
| Country of Origin | India |
| Power Output | 1200W RMS |
| Output Regulation | < 2 dB no load to full load at 1kHz |
| Click to view more | |
Product Details
Frequency Response
50 - 15000 Hz +- 3dB
S/n Ratio
60dB
Line Output
1 V/KW
Power Supply
AC:220-240V 50/60Hz (110V on request) DC:36V(3x12V Car Battery)
Protection
DC: Fuse 15Amp AC: 6Amp. Circuit Protector
AC Power Consumption
2000VA
DC Power Consumption
20A
Dimension
483 x 538 x 152 mm
Weight
36.700 Kg.
Details :
- 1 Mic/ 1 AUX Input
- Line Input for connecting the output from any external PA Mixer Amplifier
- Line output for connecting booster amplifier
- Eq on / off facility provided
- 70v / 1 OOV and 1 ohms, 2 ohms, 4 ohms output provided.
- High, mid and low three band equalizer provided for crisp and clear sound
- Led array provided to monitor output level
- Resettable circuit breaker for protection against overload and short circuit protection
- Box Speaker/Driver Unit Selector Switch
- Provided with Fan to Air Cool Circuit
- Input Channels: 1 x Mic. 0.65mV / 4.7kW (Mic source impedance 50W to 1kW) 1x Aux. 100mV / 470kW 1xCD 200mV/50W
- Tone Controls: Switch at Box Speaker Position Switch at Driver Unit Position: Bass: +-10dB at 100Hz Treble: +-10dB at 10kHz MID +- 10db at 100Hz Bass: -10dB at 100Hz Treble: +-10dB at 10kHz MID +- 10db at 100Hz
